OpenTelemetry

Oxide provides metrics natively via OxQL. For integration with external observability tools, you can use the Oxide OpenTelemetry receiver, which collects metrics from the Oxide API and exports them to any OpenTelemetry-compatible destination, such as Prometheus or Datadog.

Use the binary

The Oxide OpenTelemetry receiver runs as part of an OpenTelemetry Collector binary. First, download the binary for your OS and architecture for the latest version of the receiver:

$ OS=linux ARCH=amd64
$ curl -L -o otelcol-oxide https://github.com/oxidecomputer/oxidereceiver/releases/latest/download/otelcol-oxide-$OS-$ARCH
$ chmod +x otelcol-oxide
Note
The oxidereceiver repository provides an OpenTelemetry Collector distribution with a standard set of OpenTelemetry receivers, processors, and exporters. To change the set of OpenTelemetry components, follow the instructions in the oxidereceiver repository.

Configure the OpenTelemetry Collector

We provide an example configuration file that reads metrics from an Oxide rack and exports them using the Prometheus exposition format on 0.0.0.0:9090. To run the Collector, copy the example configuration to a new file, update it as necessary, and start the binary. The OpenTelemetry receiver supports the standard Oxide environment variables; you must set either OXIDE_PROFILE, or both OXIDE_HOST and OXIDE_TOKEN, to authenticate to the Oxide rack.

$ curl -o config.yaml https://raw.githubusercontent.com/oxidecomputer/oxidereceiver/refs/heads/main/collector/config.example.yaml
$ ./otelcol-oxide --config config.yaml

Now you can fetch current metrics using the Prometheus exposition format at localhost:9091. It may take a few seconds for all the metrics to be collected the first time.

$ curl http://0.0.0.0:9091/metrics

# HELP bgp_session:active_connections_accepted_total
# TYPE bgp_session:active_connections_accepted_total counter
bgp_session:active_connections_accepted_total{hostname="oxz_switch",local_asn="65002",otel_scope_name="",otel_scope_schema_url="",otel_scope_version="",peer="172.20.15.43",rack_id="de608e01-b8e4-4d93-b972-a7dbed36dd22",sled_id="71def415-55ad-46b4-ba88-3ca55d7fb287"} 2
bgp_session:active_connections_accepted_total{hostname="oxz_switch",local_asn="65002",otel_scope_name="",otel_scope_schema_url="",otel_scope_version="",peer="172.20.15.51",rack_id="de608e01-b8e4-4d93-b972-a7dbed36dd22",sled_id="87c2c4fc-b0c7-4fef-a305-78f0ed265bbc"} 2

See the receiver repo for configuration options and examples.

Use the container

For a more complete example, the Docker Compose quickstart runs both the OpenTelemetry Collector and a Prometheus instance to persist metrics collected from the Oxide rack.

Note
The Docker Compose manifest doesn’t mount your Oxide configuration file, so you can’t authenticate using Oxide profiles. Instead, either set the OXIDE_HOST and OXIDE_TOKEN environment variables, or add authentication details to your OpenTelemetry configuration file.
git clone https://github.com/oxidecomputer/oxidereceiver.git
cd oxidereceiver
cp collector/config.example.yaml collector/config.yaml
docker compose -f example/docker-compose.yaml up --build

Once the example is running, you can access the Prometheus user interface at http://localhost:9090. For example, you can plot average current by slot across your rack using sum by (slot) (hardware_component:current):

Prometheus Query
